ITEMS
|
UNIT
|
ZLC-700T
|
|
Clamping Force
|
kN
|
7000
|
|
Die Clamping Stroke
|
mm
|
650
|
|
Ejection Force
|
kN
|
315
|
|
Ejection Stroke
|
mm
|
155
|
|
Die Height ( Min-Max)
|
mm
|
350-850
|
|
Die Platen Size(HxV)
|
mm
|
1255×1280
|
|
Space Between Tie Bars
|
mm
|
800×800
|
|
Shot Position
|
mm
|
0，-250
|
|
Shot Strock
|
mm
|
650
|
|
Casting Force ( Intensify )
|
kN
|
590
|
|
Plunger Diameter
|
mm
|
80, 90, 100
|
|
Injection Weight(Aluminum)
|
kg
|
6.0, 7.8, 9.5
|
|
Casting Pressure (Intensify )
|
MPa
|
117, 92, 75
|
|
Casting Area
|
cm²
|
596, 754, 931
|
|
Max Casting Area(40MPa)
|
cm²
|
1750
|
|
Chamber Flange Diameter
|
mm
|
150
|
|
Height Of Pressure Chamber Flange
|
mm
|
15
|
|
Plunger Penetration
|
mm
|
290
|
|
Main Pump Driving Motor/Servo Motor
|
kW
|
37/55
|
|
Hydraulic Working Pressure
|
MPa
|
14
|
|
Oil Tank Capacity
|
L
|
1200
|
|
Machine Dimensions(LxWxH)
|
mm
|
7580x2060x3150
|
|
Referential Machine Weight For Uplifting
|
T
|
30
|
