ITEMS
|
UNIT
|
ZLC-300T
|
|
Clamping Force
|
kN
|
3000
|
|
Die Clamping Stroke
|
mm
|
470
|
|
Ejection Force
|
kN
|
150
|
|
Ejection Stroke
|
mm
|
110
|
|
Die Height ( Min-Max)
|
mm
|
250-650
|
|
Die Platen Size(HxV)
|
mm
|
860×875
|
|
Space Between Tie Bars
|
mm
|
560×560
|
|
Shot Position
|
mm
|
0，-125
|
|
Shot Strock
|
mm
|
440
|
|
Casting Force ( Intensify )
|
kN
|
330
|
|
Plunger Diameter
|
mm
|
50, 60, 70
|
|
Injection Weight(Aluminum)
|
kg
|
1.5, 2.1, 2.9
|
|
Casting Pressure (Intensify )
|
MPa
|
170, 118, 87
|
|
Casting Area
|
cm²
|
172, 252, 343
|
|
Max Casting Area(40MPa)
|
cm²
|
750
|
|
Chamber Flange Diameter
|
mm
|
110
|
|
Height Of Pressure Chamber Flange
|
mm
|
10
|
|
Plunger Penetration
|
mm
|
165
|
|
Main Pump Driving Motor/Servo Motor
|
kW
|
18.5/30
|
|
Hydraulic Working Pressure
|
MPa
|
14
|
|
Oil Tank Capacity
|
L
|
750
|
|
Machine Dimensions(LxWxH)
|
mm
|
6500×1700×2700
|
|
Referential Machine Weight For Uplifting
|
T
|
11.8
|
